x| Rated Current | 50A, 40a | IP level | IP40 |
|---|---|---|---|
| Type | Loudspeaker Connector | Gender | MALE/FEMALE |
| Industrial electronics | accessories | ||
| বিশেষভাবে তুলে ধরা | Latch Lock Cable Loudspeaker Connector,ODM Loudspeaker Connector,Screw-type Terminals Loudspeaker Connector |
||
Connection Type | SpeakON |
Gender | Male |
Contact resistance | < 2 mΩ (after lifetime) |
Dielectric strength | 3 kVdc (peak) |
Insulation resistance | > 10GΩ |
Rated current per contact | 40 A rms continuous |
Rated current per contact | 50 A audiosignal, duty cycle 50 % |
Rated voltage | 250 V ac |
Attention | SpeakON is NOT to be used as an AC mains or power supply connector! |
Service life | ＞5000 mating cycles |
Locking device | Quick Lock |
Chassis shape | Square G-size flange |
Layout | Four thru holes |
Contact plating | 4 µm Ag |
Insert | Polyamide (PA 6 30 % GR) |
Shell | Zinc diecast (ZnAl4Cu1) Ni |
Contacts | Spring Copper (CuSn0.2) |
Flammability | UL 94 HB |
Protection class | IP 50 (mated condition) |
Solderability | Complies with IEC 68-2-20 |
Temperature range | -30 °C to +80 °C |
